STELLAR PAYMENT RECONCILIATION

Every payment.
A clearer picture.

Compare your application ledger with Stellar payments.
Find discrepancies. Keep the evidence. Replay the result.

v0.3.2-preview · Windows, Linux & macOS · MIT licensed

01 / INPUT

Your payment records

Canonical JSON, CSV, or scoped SDP exports.

02 / COMPARE

Exact Stellar matching

Identity, asset, amount, and settlement window.

03 / UNDERSTAND

A replayable report

Matches, discrepancies, and unresolved evidence.

Developer preview · ordinary classic payments · read-only CLI

BUILT FOR THE MOMENT THINGS DON’T ADD UP

From payment records to clarity.

Stellar settles payments on-chain; operators keep their own payment records. When a settlement notification is missed, an amount is off by a stroop, or a record is duplicated, someone must compare an application export against the chain by hand. LedgerParity makes that comparison exact, auditable, and replayable.

What parity means here

Status. These are functional, tested libraries and a runnable CLI. They are not established operator tooling: there is no demonstrated operator adoption, no deployed SDP validation, and no production-readiness claim. Drips or partnership admission is explicitly not claimed.

OPEN SOURCE, THROUGHOUT

One workflow. Focused tools.

Matching engine

The matching engine and read-only Horizon ingestion. Normalizes and validates expectations; fetches ordinary classic payment operations within provider-declared retention; classifies matches, discrepancies, and unknowns.

Go library · Go 1.22.2+ · no external runtime dependencies · github ↗

Export connectors

Validated import of application exports: canonical JSON/CSV plus a release-pinned SDP 7.0.0 payment CSV adapter with explicit sender/network/settlement scope. Strict validation, no invented fallbacks.

Go library · synthetic contract tests · github ↗

Command-line workspace

Runnable operator workflow: configure, reconcile, capture replayable evidence, and verify byte-identical offline replays. Includes the release-scoped SDP example and a deterministic demo.

Command-line tool · v0.3.2-preview · exit codes 0/1/2/3 · github ↗

Brand & docs

Organization files, brand assets, and this documentation. See docs/SDP.md, docs/VERIFICATION.md, docs/SDP_EVIDENCE.md, and the audit docs/GAP_ASSESSMENT.md for detailed evidence.

Static site · no build step · brand kit in brand/

Concepts

Exact identity

A settlement matches only when all identity dimensions agree: network passphrase, sender, recipient, asset type, asset code and issuer (case-sensitive for credit assets), and the time window. An operation_id disambiguates multiple payments inside a single transaction. A token contract address is never an issuer alias.

Amounts

Values are exact stroop integers within the signed int64 range, including at the limit. Inputs with excess precision fail validation; amounts are never rounded and no monetary tolerance is applied.

Time windows

A record supplies exactly one representation: a legacy timestamp or an explicit settlement_start/settlement_end interval. Intervals are closed and are not widened by time tolerance; they must fit the reconciliation window. A partially intersecting interval is reported, never silently filtered. business_reference is separate from reference_id, which means the transaction hash only — never a memo.

Coverage and UNKNOWN

Coverage is provider evidence, not a cryptographic history proof. A complete scan means provider-declared retained history encloses the requested window, pages were traversed, and the retention boundary stayed stable. Incomplete coverage, ambiguous multiple candidates, competing claims, and malformed observations all remain UNKNOWN. Unknowns are reported separately and are not counted as financial discrepancies.

The legacy slice-only FetchOnChainPayments wrapper discards coverage and is unsuitable for definitive absence conclusions.

Horizon ingestion

The ingestor traverses descending numeric paging tokens against the configured endpoint (no arbitrary redirects or next-links), verifies the network passphrase before and after the scan, enforces request/response size and retry bounds, stops on failure with no successful ingestion result, and never lets an error become an empty scan. Durable checkpoints and crash-restart resume are not implemented; scans restart intentionally.

RPC corpus (developer tool)

A separate Node developer tool (tools/rpc-corpus) performs opt-in public-testnet reads only: getNetwork/getTransaction JSON-RPC and Horizon GET. It never signs, funds, or simulates. It captures ordinary-payment transactions and verifies that RPC results agree with Horizon operation semantics. Runtime ingestion in the Go modules remains Horizon-only.

TRY THE WORKFLOW

Your first replay, in minutes.

Download and extract the preview for your platform. Open a terminal in the extracted folder and run this synthetic example. On Windows PowerShell, use .\ledger-parity.exe; on macOS and Linux, use ./ledger-parity.

CLI — offline SDP example

ledger-parity --config examples/sdp/config.json \
  --bundle evidence.json --out report.json
# exit 3: 1 match, 1 discrepancy, 1 unresolved (fixture)

ledger-parity --replay evidence.json --out replayed.json
# byte-identical report; exit 3

Exit codes

CodeMeaning
0Complete match — no discrepancies, no unknowns.
1Runtime or configuration error — nothing produced.
2Financial discrepancies found.
3Unresolved evidence present (UNKNOWNs are never counted as discrepancies).

Example scope discipline. The SDP workflow requires an independently known sender, network, and closed settlement interval declared by the caller. CSV creation/update time is never settlement time; the caller's interval is an assertion, not source-certified execution time.

Build from source & library examples

Requirements

Go 1.22.2 or newer (a currently supported Go release is preferred). The RPC corpus uses Node 22+ with the pinned @stellar/stellar-sdk (npm ci).

Run the tests from any checkout

go test ./...
go vet ./...
go build ./...

Library flow (core)

h := ingest.NewHorizonIngestor("https://horizon-testnet.stellar.org")
h.Network = "Test SDF Network ; September 2015"   // exact passphrase

res, err := h.Fetch(ctx, accounts, start.Add(-tol), end.Add(tol))
// pass res.Coverage into ReconcileOptions; set Coverage.InternalComplete
// only if the export covers every relevant ordinary payment.

opts := engine.ReconcileOptions{TimeframeToleranceSec: tol, Coverage: res.Coverage}
report := engine.NewReconciler(opts).Reconcile(
    app, start, end, internalPayments, res.Payments)

Connectors (import exports)

ips, err := sdp.Parse(csvReader, network, "deployment-name", sdp.Scope{
    Release: sdp.Release, Sender: "GB…", Assertion: "…",
    SettlementStart: start, SettlementEnd: end,
})

Evidence you can revisit.

The optional report hash contract has synthetic Protocol 28 testnet validation, including authorized registration, read-back, early renewal and measured fees. It records a hash assertion; it does not prove reconciliation correctness. Archived restoration and real operator validation remain outstanding.

The CLI can capture an evidence bundle (ledgerparity-evidence/v1) alongside a report: the scoped inputs, coverage metadata, tool/build hashes, and the produced report. This makes an operator finding inspectable and reproducible without the original network or export host.

Evidence limits. Coverage trusts the configured provider and does not prove cryptographic or continuous history. SDP adapters are tested against the pinned upstream contract plus synthetic exports, not a deployed SDP installation. The RPC corpus contains one captured public-testnet fixture plus synthetic mutations. Nothing here is fabricated to look validated.

Security and trust

Read security and trust guidance
  • The reconciliation CLI never needs secret keys and never signs or submits transactions. The optional contract has separate signed testnet validation tooling.
  • Treat exports and reports as sensitive — they contain account identifiers, amounts, and application references; keep them out of public commits. JSON files are created with private permissions where the OS supports it; Windows ACLs and pre-existing files need operator management.
  • Horizon is a trusted data provider, not a locally verified ledger proof. Configure an endpoint you trust; do not expose the CLI as a service accepting arbitrary URLs or files.
  • Exact account equality does not validate StrKey checksums; muxed identities are preserved with conservative base-account coverage limitations.
  • For a sensitive bug, use each repository's GitHub Security → Report a vulnerability if available; otherwise open a minimal issue without disclosing secrets, customer data, or exploit details. Per-repository guidance is in each SECURITY.md.

Roadmap and status

AreaStatus
Exact classic-payment matching (amounts, identity, intervals, UNKNOWN semantics)Implemented and tested, including negative and edge cases.
Replayable SDP evidence workflow and byte-identical replaysImplemented with synthetic contract tests.
Read-only Horizon ingestion with retention/freshness boundsImplemented; RPC migration remains unproven (one captured fixture).
Real operator validationOpen — needs an independently produced sanitized operator export and a known discrepancy.
Credit-asset / fee-bump RPC fixturesOpen — needs real captured transactions, per the no-fabrication rule.
Durable checkpoints and crash/restart resumeOpen — separate design required before advertising.
Path payments, Soroban/RPC runtime ingestion, signing or restitutionOut of scope for the preview.

See ROADMAP.md and docs/backlog.md in each repository for the acceptance criteria behind these rows. Current check results live in PROJECT_HANDOFF.md, never as future milestone promises.

Governance and community

Read governance and community guidance

LedgerParity is maintained as an honest, evidence-first preview. Decisions are recorded in each repository's DECISIONS.md; corrections are added rather than history being rewritten.

  • Organization files — code of conduct, governance, license.
  • Per-repository CONTRIBUTING.md, SECURITY.md, DECISIONS.md, and docs/backlog.md for contributor tasks.
  • All repositories are MIT licensed; brand usage and honesty rules remain applicable regardless of license terms.
  • The brand is original and deliberately distinct from the Stellar Development Foundation's brand; no affiliation is claimed.
